U.2

FSN2E-W Series
  • Specifications
  • Model No.
  • Related Materials
LIG-JB17P

SPECIFICATIONS

Model Name FSN2E-W Series
Interface PCIeGen 4 x 4
Flash Type 3D TLC
Formfactor U.2
Capacity 960GB～3,840GB
Dimension（mm） 69.85 x 100.00 x 7.00
Sequential Read/Write(MB/s) 3,000 / 2,900
Supply Voltage 12V±5%
Shock resistance 14,709 m/s2 (1500G) (MAX)
Vibration resistance 160.0 m/s2 16.4G peak (10-2,000 Hz)
Storage temperature Standard Temperature product(-40℃～85℃)
Wide Temperature product(-45℃～90℃)
Operating temperature Standard Temperature product(0℃～70℃)
Wide Temperature product(-40℃～85℃)
TBW 750TB～4,000TB

MODEL NUMBER

Standard Temperature product(0℃～70℃） Wide Temperature product（‐40℃～85℃）
960GB FSN2E-960GW**CN FSN2E-960GW**DI
1,920GB FSN2E-1920W**CN FSN2E-1920W**DI
3,840GB FSN2E-3840W**CN FSN2E-3840W**DI
